Gricad clusters#

[First connection](#First connection)
[Running jobs on Gricad clusters](#Running jobs on Gricad clusters)
[Storage on Gricad clusters](#Storage on Gricad clusters)
[Elmer usage on Gricad clusters](#Elmer usage on Gricad clusters)

First connection#

More details about Gricad infrastructure are available here:

https://gricad-doc.univ-grenoble-alpes.fr/hpc/

Get your account on Gricad

If you have an agalan login/password, create your account here

if not, create an external account with the email from your institution (private email @gmail/@yahoo are not allowed) here

Once you created your account, you should receive an email from perseus that asks you to validate your account with a KEY provided in the email

Connect again to perseus and enter the provided KEY et it should be ok.

It should take 1 day to get your account activated. If you nee a rapid accesss, feel free to contact mondher.chekki@XXXXX

Create an ssh key

ssh-keygen -t rsa

Type Enter twice WITHOUT ENTERING ANY PASSWORD and you should have two keys in $HOME/.ssh

a private key: id_rsa
a public key : id_rsa.pub

Create config file

Then create the $HOME/.ssh/config file on your computer , in which you must enter the bastion and server information for the connection.

For Dahu server:

Host dahu
ProxyCommand ssh -qX login_gricad@trinity.u-ga.fr nc 129.88.197.54 22
User login_gricad
GatewayPorts yes

replace login_gricad with yours

Next, you need to set the correct rights:

chmod ugo-rwx .ssh/config
chmod u+rw .ssh/config

keep read/write rights only for the user and the private key: id_rsa

Then, copy the ssh keys

ssh-copy-id login_gricad@trinity.u-ga.fr

Enter the agalan passwod

then

ssh-copy-id dahu

Enter the agalan password

and you should be good for future sessions.

Now, to connect, just type

ssh dahu

Running jobs on Gricad clusters#

Once you are connected to dahu, you will be able to run jobs with the scheduler named OAR

An introduction to OAR is described here

Basically, to perform computations, you don’t have to do them on the server you’re connected to (front-end), but on other servers (compute nodes) accessible from the front-end.

Hence you need to use a job scheduler (OAR) to launch calculations on the nodes.

For example, let’s say that you need to run R calculations on the server :

To install R packages, either use nix or guix environement or use micromamba
Here’s an example of a job header:

$ cat job_exemple.oar

#!/bin/bash
#OAR -n Test_job
#OAR -O Test_job.%jobid%.o
#OAR -E Test_job.%jobid%.e
#OAR --project sno-elmerice
#OAR -l nodes=1/core=1,walltime=01:30:00

cd YOUR_WORKING_DIRECTORY
micromamba activate Renv

R CMD BATCH ....
or
Rscript ....

Change the name of project to your project

Description:

#OAR -l nodes=1/core=1,walltime=01:30:00

Launch of a job, on a single computing core for 1h30 (possibility of increasing core=1 a plus when using MPI)
The project on which the hours will be used is sno-elmerice

The results will be written to two files

#OAR -O Test_job.NUMERO_JOB.o (standart output)
#OAR -E Test_job.NUMERO_JOB.o (standart error)

If you want to use the fat nodes, just add this to your script:

#OAR -t fat

If you need to use immediatly the node without waiting add this (yo need to asked for a walltime less than 30 minutes

#OAR -t devel

Memory

You have different type of nodes with different features (use recap.py to see all of them).

The memory you are using in a job is equal to:

n_cores_asked x ( total_mem/n_cores)

If you want the whole memory, you should asked for all available cores (n_cores) in one node

[f-dahu /home/chekkim ]$ recap.py
========================================================================================
| node | cpumodel |n_cpus n_cores| scratch1_type | hasgpu |
| | | total_mem| scratch2_type | |
========================================================================================
| dahu33 | Gold 6130 | 2 | 16 | 192 |dedicated_ssd | dedicated_hdd | NO |
| dahu34 | Gold 6130 | 2 | 32 | 192 |dedicated_ssd | dedicated_hdd | NO |
| [ + 37 more node(s) ] |
| dahu72 | Gold 6130 | 2 | 32 | 192 |dedicated_ssd | dedicated_hdd | NO |
| dahu73 | Gold 6126 | 2 | 24 | 192 |system_ssd | dedicated_hdd | NO |
| [ + 2 more node(s) ] |
| dahu76 | Gold 6126 | 2 | 24 | 192 |system_ssd | dedicated_hdd | NO |
| dahu77 | Gold 6126 | 2 | 24 | 192 |dedicated_ssd | dedicated_hdd | NO |
| [ + 3 more node(s) ] |
| dahu81 | Gold 6126 | 2 | 24 | 192 |dedicated_ssd | dedicated_hdd | NO |
| dahu82 | Gold 6130 | 2 | 32 | 192 |dedicated_ssd | dedicated_hdd | NO |
| [ + 23 more node(s) ] |
| dahu106 | Gold 6130 | 2 | 32 | 192 |dedicated_ssd | dedicated_hdd | NO |
| dahu107 | Gold 6130 | 2 | 32 | 192 |dedicated_ssd | none | NO |
| dahu108 | Gold 5218 | 2 | 32 | 192 |dedicated_ssd | dedicated_hdd | NO |
| dahu109 | Gold 5218 | 2 | 32 | 192 |dedicated_ssd | dedicated_hdd | NO |
| dahu110 | Gold 6244 | 2 | 16 | 192 |dedicated_ssd | none | NO |
| dahu111 | Gold 6244 | 2 | 16 | 192 |dedicated_ssd | none | NO |

| dahu142 | Gold 5218 | 2 | 32 | 192 |dedicated_hdd | none | NO |
| dahu143 | Gold 5218 | 2 | 32 | 192 |dedicated_hdd | none | NO |
| dahu144 | Gold 5318Y| 2 | 48 | 256 |system_ssd | none | NO |
| [ + 47 more node(s) ] |
| dahu192 | Gold 5318Y| 2 | 48 | 256 |system_ssd | none | NO |
| dahu-fat1| Gold 6244 | 2 | 16 |1500 |dedicated_raid0_ssd | dedicated_raid5_hdd| NO |
| dahu-fat2| Gold 6244 | 2 | 16 |1500 |dedicated_ssd | dedicated_hdd | NO |
| [ + 1 more node(s) ] |
| dahu-fat4| Gold 6244 | 2 | 16 |1500 |dedicated_ssd | dedicated_hdd | NO |
| dahu-visu| Silver 4216| 2 | 32 | 192 |system_hdd | none | NO |
========================================================================================

To run the job do

chmod 750 job_exemple.oar
oarsub -S ./job_exemple.oar

Use the interactive mode

If you are developping a code, it is better to have acces to a node for debugging issues. In the passive mode, if you make a small mistake, then you have to submit your job again and wait in the queue. Using the interactive mode allows to correct your mistake and run your code until you make sure that everything is working fine.

To do that use oarsub with -I command:

oarsub -I -l nodes=1/core=1,walltime=01:30:00 --project sno-elmerice

for devel mode

oarsub -I -l nodes=1/core=1,walltime=00:30:00 --project sno-elmerice -t devel

for fat nodes

oarsub -I -l nodes=1/core=1,walltime=04:30:00 --project sno-elmerice -t fat

Job Stats with OAR

Once your job is finished or in case it stops without any reasons, you can check the dashboard

Warning

Replace MYJOBID with your JOBID

https://gricad-dashboards.univ-grenoble-alpes.fr/d/RUyeEaIGz/colmet-dahu-jobs-stats?orgId=1&refresh=1h&var-Job_ID=**MYJOBID**&var-Node=All&from=now-24h&to=now

Here is an example of Memory usage for different nodes

Dashbord Memory usage example

Storage on Gricad clusters#

Workdir/Datastorage on dahu

You have access to the $HOME(/home/your_login), which is a limited space under quota (50GB max).

You must work on /bettik/login_gricad, /bettik/PROJECTS/PROJECT_NAME/login_gricad or /bettik/PROJECTS/PROJECT_NAME/COMMON if you want to share you data/code between the members of the project

Bettik is a parallel filesystem so it is very fast when it comes to write/read data by the same program with different tasks

This space is accessible to all nodes.

More info on Gricad Website

To copy data from your PC to /bettik, use the rsync command.

For example :

Let’s assume we have a folder: Data_Model
We’d like to copy this folder to /bettik/login_gricad in order to use the data.
The copy is made with the command rsync:

rsync -rav Data_Model dahu:/bettik/login_gricad/

To copy data from dahu to your PC:

rsync -rav dahu:/bettik/login_gricad/Dossier_bettik .

Warning

be careful there’s the dot . which means copy here

If you have a local folder called Local_folder to which you want to copy data from /bettik

rsync -rav dahu:/bettik/login_gricad/Dossier_bettik/ Local_folder/

Warning

If you want to transfer huge data or a lot of files use mantis-cargo instead See https://gricad-doc.univ-grenoble-alpes.fr/hpc/data_management/data_transfer/ Replace dahu by mantis-cargo.u-ga.fr in the previous commands

Other Datastorage available on dahu: /silenus and /mantis

Silenus is a parallel filesystem composed of SSD so it is very fast but consider this as a scratch as the files will be automatically deleted when they reach 60 days old.

So If you need to save them, you have to copy them to /bettik workdir for short term preservation(<1an), or to the Mantis2 cloud storage for long term preservation(<5ans).

Warning

If your files are only accessed in read mode, and you still use them, you should do a touch <file> or touch -r <directory> to update the change time as HPC scratches do not update the access time. Otherwise, they may be deleted 60 days after their creation.

Mantis is a cloud storage used for long term preservation

First usage of mantis

Copy this file to your $HOME/.irods directory on dahu, keep the same name and put your login instead of chekkim

[f-dahu  /home/chekkim ]$  more .irods/irods_environment.json
{
        "irods_host": "mantis.u-ga.fr",
        "irods_port": 1247,
        "irods_user_name": "chekkim",
        "irods_zone_name": "mantis",
        "irods_authentication_scheme": "PAM",
        "irods_ssl_ca_certificate_file": "/etc/irods/chain.pem",
        "irods_ssl_verify_server": "cert"
}

and then connect using iinit

f-dahu  /home/chekkim ]$  iinit
Enter your current PAM password:
[f-dahu  /home/chekkim ]$  ils
/mantis/home/chekkim:
  bench_v1.tar
  elmerscalasca.tar
  netcdf-cxx4-4.3.1.tar.gz
  C- /mantis/home/chekkim/MARin
  C- /mantis/home/chekkim/input
  C- /mantis/home/chekkim/python

Enter your agalan password and you should be able to copy/get files to your mantis workspace using iget and iput commands

More details , here:

https://gricad-doc.univ-grenoble-alpes.fr/hpc/data_management/mantis/

/home OR /bettik OR /silenus OR /mantis , how to choose

/home you should put here all your scripts, code in python/bash/fortran/R and you should manage to save them (the /home is no longer saved) You should also think about using github or Gricad gitlab to commit you changes and keep your codes up to date

/bettik should be used by default for all your simulations as you have a large quota and your data is not cleaned.

/silenus should be tested with your workflow and see if the access to data is faster and in this case re-organise you workflow to move your data older than 60 days from silenus

/mantis is used in case you have cold data on /bettik that you are not going to use for a while ( let say < 6 months) but you need this data for future simulations

Elmer usage on Gricad clusters#

Once connect to dahu, first install the intel compilers

source /applis/site/nix_nur.sh
nix-env -i -A nur.repos.gricad.intel-oneapi

In case the previous command does not work, or generates erros , you can install intel compilers from my profile

nix-env -i --from-profile /nix/var/nix/profiles/per-user/chekkim/env_inteloneapi intel-oneapi

Once the intel compilers installed, in order to use them

source /applis/site/nix_nur.sh
source ~/.nix-profile/setvars.sh >/dev/null

In order to load Elmer modules , you have to put this on a config file myconfig.sh or in your $HOME/.bashrc and source it each time you need to use it

Warning

If you put this in your .bashrc , it will be sourced automatically but may create conflict with other applications

source /applis/site/nix_nur.sh
source ~/.nix-profile/setvars.sh >/dev/null
 . /home/chekkim/LibGlace/versions/modules/modules_rev4401cc7d_gnu6.3.0/init/bash
export MODULEPATH=/home/chekkim/LibGlace/modulefiles
module load  netcdf/netcdf-4.7.2_intel21_hdf5_MPIO  xios/xios-2.0_rev2320_intel21    elmerfem/elmerfem-22c2e6b30_intel21

then

source $HOME/.bashrc
or
source  myconfig.sh

For the intel compilers you need to add this in your $HOME/.bashrc file in order to avoid seg fault errors when running jobs across nodes

ulimit -s unlimited

And it should be ok. In order to acces other versions of elmer you can check it with the command

module avail elmerfem

In order to get rid of the old module, you need to modify your $HOME/.bashrc or your config file

In order to test it on a terminal: this will not change the version you put on the $HOME/.bashrc or config file, but only affects the terminal you are using

module unload elmerfem
module load elmerfem/elmerfem-XXXXX
or
module switch old_module_name  new_module_name
